the siphon socket (1,5 - 2 t)
casting semi-automatic machine WOHR (2t)

1 long-term cold blast cupola furnace of diameter 1 000 mm
2 forehearts 20 t "PIKS 20"
2 induction furnaces JUNKERS (2,5 t)

• The automatic moulding „GEORG FISCHER“
-  dimension of moulding frame 1 200 x 1 000 x 350/350 mm
   modernization by change of forming machine
   KÜNKEL-WAGNER in 2011

• The mechanical moulding
-  2 x moulder Retomat F30
   900 x 500 x 200/200* 300/300 mm
-  2 x moulder Foromat F30
   900 x 500 x 200/200* 300/300 mm
-  2 x moulder Foromat F40
   1 050 x 800 x 200/200* 300/300 mm

• The hand moulding
-  dimension of moulding frame from - 550 x 550 till 2 500 x 2 500 mm
-  the moulding sand - mixture with the Alphaset
-  continuous mixer (20t/h) FAT
-  Sand reclamation plant mady by OMEGA foundry machinery

Melting agregates

Castings

Moulding

Core Production

• Mechanical core production (Cold-Box)
-  one machine LAEMPE LL10
-  three machines LL20
• Hand (Alphaset)
-  continuous mixer FAT (6t)

-  4 Shot-blasting (continuous/hanging, 2 tables, drum shot-blastings)
-  annealing and hardening furnace
-  grinding machines
• Surface finishing of castings:
-  coloring line with drying

•  tests of properties of moulding sands
•  chemical analysis of liquid metal and solid starting metal-materials
•  metallographic analysis
•  tests of mechanical properties of castings
•  non-destructive testings
    -  capillary test
    -  magnetic powder test
    -  ultrasonic inspection - in cooperation
    -  inspection of RTG - in cooperation
•  3D dimensional inspection - ROMER arm
•  endoscopy

Cleaning of castings

Quality control and management
